3M

3M CBRN Gas Cartridge - 4/Box - FR-15-CBRN

(No reviews yet) Write a Review
SKU:
329-3MFR-15-CBRN
UPC:
50051131529910
MPN:
7000052356
Availability:
Call or Email for Availability!
Shipping:
Calculated at Checkout
MSRP: $448.83
Now: $391.35
— You save $57.48

Description

3M CBRN Gas Cartridge - 4/Box - FR-15-CBRN

This canister is designed for first responder applications commonly found in law enforcement, fire and emergency response (paramedics) environments. Unique, patented carbon technologies make this cartridge more comfortable for the wearer.

Approved to NIOSH Chemical Biological Radiological Nuclear (CBRN) requirements in conjunction with the following 3M™ Full Facepiece Respirators: FR-M40B-10, Small; FR-M40B-20, Medium; FR-M40B-30, Large and FR-7800B-S, FR-7800B-M and FR-7800B-L.

  • Designed for first responder applications commonly found in law enforcement
  • DIN cartridge connection type
  • 4 canisters per case
  • 3M™ FR-7800B Series and 3M™ FR-M40B Series

40mm NATO threaded design preferred by law enforcement

FR-15-CBRN Canister Specifications Can filter a wide range of chemical warfare agents such as:

  • Nerve agents: tabun (GA), sarin (GB), soman (GD), VX.
  • Mustard/Blister agents: H, HD, L.
  • Tear agents: CN, CS, CR, OC.
  • Blood agents: hydrogen cyanide (AC), cyanogen chloride (CK), arsine (SA).
  • Choking agents: chlorine, phosgene, chloropicrin (PS), and diphenylchloroarsine (DA).

Can also filter common industrial chemicals such as:

  • Organic vapors
  • Chlorine dioxide, chlorine, hydrogen fluoride, hydrogen sulfide and sulfur dioxide
  • Ammonia, methylamine
  • Formaldehyde
  • Nitrogen dioxide
  • Phosphine
  • Particles
Industrial Category: Safety
Industrial Subcategory: Respiratory
Industrial Subtype: Gas Mask Canisters
Accessories: No
Enhanced Comfort: No
Enhanced Durability: No
Eye Protection: No
Harmonized Tariff Schedule Nbr: 8421990080
Maintenance Free: No
Product Type: Filter & Cartridge
Recommended Industry: Military Tactical
Silicone Faceseal: No
Six-point Head Harness: No
Spare Parts: No
Speaking Diaphragm: No
UPC Code: 50051131529910
Manufactured By: 3M
Test Results for Canister FR-15-CBRN
Challenge Agent Challenge Concentration (ppm) Testing Relative Humidity
(%)		 Maximum Allowed Breakthrough (ppm) Minimum Test Time (min) TLV®1  / IDLH2
(ppm)		 Maximum Use Concentration3 (ppm)
Ammonia (NH3)4 1000 50 50 > 25 25 / 500 500
Ammonia (NH3)5 2500 25 / 80 12.5 > 15 25 / 500 500
Chlorine Dioxide (ClO2)4 500 50 0.1 > 30 0.1 / 10 10
Carbon Tetrachloride
(Organic Vapors)4		 1000 50 5 > 25 5 / 300 250
Chlorine (Cl2)4 500 50 5 > 17.5 0.5 / 30 25
a-Chloroacetophenone (CN)4, 6 16 50 0.05 > 480 0.05 / 16 2.5
o-Chlorobenzylidenemalononitrile
(CS)4, 6		 3 50 0.05 > 480 0.05C7  / 0.25 0.25
Chloropicrin (PS)8 744 80 0.74 > 27 0.1 / 4.0 4
Cyanogen Chloride (CK)5 300 25 / 80 2 > 15 0.3C7  / ND (46.9)9 15
Cyanogen Chloride (CK)10 1591 80 3.2 > 30 0.3C7  / ND (46.9)9 15
Cyclohexane (Organic Vapors)5 2600 25 / 80 10 > 15 100 / 10000 5000
DMMP10, 11 591 Dry 0.008 > 59 NA NA
Formaldehyde (CH2O)4 100 50 1 > 50 0.3C7  / 30 7.512
Formaldehyde (CH2O)5 500 25 / 80 1 > 15 0.3C7  / 30 7.512
Hydrogen Chloride (HCl)4 500 50 5 > 25 2C7  / 100 100
Hydrogen Cyanide (AC)13 3618 80 4.514 > 28 4.7C7  / 50.0 50
Hydrogen Cyanide (AC)5 940 25 / 80 4.715 > 15 4.7C7  / 50.0 50
Hydrogen Fluoride (HF)4 70 50 3 > 30 3C7  / 30 30
Hydrogen Sulfide, Escape (H2S)4 1000 50 10 > 30 10 / 300 300
Hydrogen Sulfide, Escape (H2S)5 1000 25 / 80 5 > 15 10 / 300 300
Methylamine (CH3NH2)4 1000 50 10 > 12.5 5 / 100 100
Nitrogen Dioxide (NO2)5 200 25 / 80 1 ppm NO2  or 25 ppm NO > 15 3 / 50 50
Particulates (P100)4 200 mg total loading w/ 0.3µm MMAD DOP particles NA <0.03% 240016 10 mg/m3  I17  / ND
3 mg/m3  R18  / ND		 500 mg/m3
150 mg/m3
Phosgene (CG)13 4943 50 2 > 25 0.1 / 2.0 2
Phosgene (CG)5 250 25 / 80 1.25 > 15 0.1 / 2.0 2
Phosphine (PH)4 1500 50 0.3 > 12 0.3 / 200 15
Phosphine (PH)5 300 25 / 80 0.3 > 15 0.3 / 200 15
Sulfur Dioxide (SO2)4 500 50 5 > 15 2 / 100 100
Sulfur Dioxide (SO2)5 1500 25 / 80 5 > 15 2 / 100 100
NA = Not applicable
ND = Not Determined
ppm = parts per million
mg/m3 = milligrams per cubic meter of air



3M ID: 70071092970

UPC/GTIN: 50051131529910
